Magic LED Ball
Spherical geometry for 360 degree viewability
Display creative and attractive content
State-of-the-art LED display technologies for seamless experience
Suitable for eye catching applications: Casinos, Shopping Malls, Entertainment Venues, Exhibition, Museum, Attractions
| Specification | 1.2m LED Ball | 1.8m LED Ball |
|---|---|---|
| Total Pixel | 202,000 | 450,680 |
| Viewing Area (㎡) | 4.67 | 10.56 |
| Diameter (m) | 1.22 | 1.834 |
| Maximum Power Consumption (kw) | 4.8 | 14.4 |
| Average Power Consumption (kw) | 1.6 | 4.8 |
| Net Weight (kg) | 125 | 410 |
| LED Configuration | SMD2121 | SMD2121 |
| Viewing Angle (degrees) | 120 | 120 |
| Pixel Pitch (mm) | 4.8 | 4.8 |
| Service Method | Front Service | Front Service |
| Brightness (nits) | 1500 | 1500 |
| Pixel Count Per Square M | 43264 | 43264 |
| Voltage (V) | AC220/380 50Hz | AC220/380 50Hz |
| Grey Scale | 16384 | 16384 |
| Refresh Rate (Hz) | >1920 | >1920 |
| Ingress Protection | IP21 | IP21 |
