Powerlite – Perimeter

Optiz’s Powerlite Perimeter P10 Screen keep players, coaches and fans informed of current game information while identifying the facility or recognizing sponsors. Cabinet size of 1280×960mm for either fixed installation or fast rigging rental applications. Designed to endure the harsh impacts of sports and outdoor weather conditions.

Model Powerlite 10
Pixel Pitch (mm) 10
Pixel Density (Pixels/Sqm) 10,000
Module Dimensions (mm) 320 (W) x 210 (H)
Cabinet Dimensions (mm) 1280 (W) x 960 (H)
Cabinet Material Precision Extruded Aluminium
Cabinet Weight (kg) 40kg
Constant Color Range 281 Trillion Colors
Brightness (nits) 6000
Viewing Angles H: 140 degrees V: 110 degrees
Contrast Ratio 2000:1
Brightness Adjustment Manual 256 level; Auto 8 level
Screen Power Consumption Max: 800W/pcs Average: 350W/pcs
Grey Scale 65,536 Shades Per Color
Input Voltage AC110V/220V
Input Frequence 50/60Hz
Ingress Protection Front IP65/Back IP65
Refresh Rate >2500Hz
