Slimmer & Lighter. Built for Rental and Staging Applications
Seamless Design. Manufactured with maximum precision
Designed for outdoor. Stable Power Supply Modules designed to be waterproof and reliable heat dissipation
Tool Free Installation. Advanced interlocking system and integrated handle design
Self Inspection Function. Hassle Free maintenance
| Model | RK6 | RK8 | RK10 |
|---|---|---|---|
| Pixel Pitch (mm) | 6.6 | 8 | 10 |
| Brightness(nits) | 5500 | 5000 | 5500 |
| Viewing Angle(deg.) | 140(Horizontal), 120(Vertical) | 140(Horizontal), 120(Vertical) | 140(Horizontal), 120(Vertical) |
| LED Configuration | SMD | SMD | SMD |
| Panel Size(mm) | 640(W)x720(H) | 640(W)x720(H) | 640(W)x720(H) |
| Panel Resolution(pixels) | 96×108 | 80×90 | 64×72 |
| Cabinet Material | Die-Casting Aluminium | Die-Casting Aluminium | Die-Casting Aluminium |
| Panel Weight(kg) | 13.5 | 13.5 | 13.5 |
| Max. Hanging Panel Quantity (Vertical) | 15 | 15 | 15 |
| Protection Grade(Front/Rear) | IP65/IP43 | IP65/IP43 | IP65/IP43 |
| Serviceability | Rear | Rear | Rear |
| Voltage(V) | AC110-AC240 | AC110-AC240 | AC110-AC240 |
| Avg. Power Consumption (W/㎡) | 300(AC) | 275(AC) | 290(AC) |
| Operating Tem/Humidity((℃/%RH) | 20~50/10-90 | 20~50/10-90 | 20~50/10-90 |
| Compliant Standard | CE FFCC RoHS | CE FFCC RoHS | CE FFCC RoHS |
